Type
|
36 x 24 mm Full Frame back-illuminated stacked CMOS sensor
|
|
Effective Pixels
|
Approx. 45 megapixels
|
|
Total Pixels
|
Approx. 50.3 megapixels
|
|
Low-Pass Filter
|
Built-in/Fixed
|
|
Sensor Cleaning
|
EOS integrated cleaning system
|
|
Colour Filter Type
|
RGB Primary Colour
|
|
Sensor Shift-IS
|
Yes, up to 8.5-Stops advantage at the center and 7.5-stops peripheral depending on the lens used
|
| Type |
DIGIC Accelerator and DIGIC X
|
|
Lens Mount
|
RF / RF-S
EF and EF-S lenses can be attached using: Mount Adapter EF-EOS R Control Ring Mount Adapter EF-EOS R, Drop-In Filter Mount Adapter EF-EOS R
EF-M lenses are not compatible |
|
Focal Length
|
Equivalent to 1.0x the focal length of the lens with RF and EF lenses, 1.6x with EF-S and RF-S lenses.
|
| Type |
Dual Pixel Intelligent AF
|
|
AF Positions
|
100% horizontal and 100% vertical with Face + Tracking and Auto Selection modes
100% horizontal and 90% vertical with manual selection and large zone modes |
|
AF Working Range
|
EV -6.5 – 21 (at 23°C & ISO100) |
|
AF Modes
|
One Shot, Servo AF, AI Focus AF (in A+ Scene Intelligent Auto mode )
|
|
AF Point Selection
|
Automatic selection: Face + tracking. 1053 Available AF areas when automatically selected
Manual selection: Spot AF
Manual selection: 1-point AF (AF frame size can be changed) 5850 (stills)/ (4500) movie AF positions available
Manual selection: AF point Expansion 4 points (up, down, left, right)
Manual selection: AF point Expansion surrounding
Manual selection: Flexible Zone AF 1-3 (all AF points divided into minimum 9 to 999 maximum focusing zones, where the width and hight is also adjustable)
Manual selection: Whole area AF
Manual selection: Spot AF (Whole area tracking servo AF OFF)
Manual selection: 1-point AF (Whole area tracking servo AF OFF)
Manual selection: AF point Expansion 4 points (up, down, left, right) (Whole area tracking servo AF OFF)
Manual selection: AF point Expansion surrounding (Whole area tracking servo AF OFF) |
|
AF Tracking
|
Humans (Eyes, Face, Head, Upper half of body, Body), Animals (Dogs, Cats, Birds and Horses) or Vehicles (Racing cars or Motor bikes, Airplanes and Trains), Register People Priority (up to 10 x 10 registered people), Action Priority (Football, Basketball, Volleyball)
Supported actions:
- Soccer: Shoot, header, short pass, long pass, dribble, clear, place kick, save by keeper, throw in, sliding tackle
- Basketball: Shoot, rebound, pass, dribble, free throw, jump ball
- Volleyball: Spike, toss, receive, serve |
|
|
Locked when shutter button is pressed halfway or AF ON is pressed in One Shot AF mode. Using customised button set to AF stop in AI servo |
|
|
Emitted by built in LED or optional dedicated Speedlite (flash)
|
|
|
|
|
Metering Modes
|
Real-time with image sensor, 6144-zone metering.
(1) Evaluative metering (linked to All AF points)
(2) Partial metering (Approx. 9.5% of screen at centre)
(3) Spot metering: Centre spot metering (Approx. 5.3% screen at centre) AF point-linked spot metering not provided
(4) Centre weighted average metering
|
|
Metering Brightness Range
|
EV -3 – 20 (at 23°C, ISO100, with evaluative metering)
|
|
AE Lock
|
Auto: AE lock takes effect when focus is achieved Manual: By AE lock button in P, Av, Fv, Tv and M modes
|
|
Exposure Compensation
|
+/-3 EV in 1/3 or 1/2 stop increments (can be combined with AEB)
|
|
Anti-flicker Shooting
|
Yes. Flicker detected at a frequency of 100 Hz or 120 Hz. Maximum continuous shooting speed may decrease available with both electronic and mechanical shutter
High Frequency anti flicker shooting for M and TV modes
Electronic 1st-curtain: 1/50.0 to 1/2048.0 sec.
Electronic shutter: 1/50.0 to 1/8192.0 sec.
Movie recording: 1/50.0 to 1/8192.0 sec. (NTSC/PAL)
Maximum continuous shooting speed may decrease.
|
| ISO Sensitivity |
Auto 100-51200 (in 1/3-stop or 1 stop increments)
ISO can be expanded to L:50, H1:102400
|
|
Type
|
Electronically-controlled focal-plane shutter and Electronic shutter function on sensor
|
| Speed |
Mechanical / Electronic 1st-curtain: 30-1/8000 sec (1/2 or 1/3 stop increments), Bulb
Electronic: 30-1/32000 (1/2 or 1/3 stop increments up to 1/16000 then 1 stop until 1/32000), Bulb
(Total shutter speed range. Available range varies by shooting mode)
|
|
Shutter Release
|
Soft touch electromagnetic release
|
|
Type
|
8.0cm (3.2") TFT Colour LCD, approx. 2.1million dots
|
| Coverage |
|
| Viewing Angle (Horizontally/Vertically) |
Approx. 170° vertically and horizontally
|
|
Coating
|
Anti-smudge coating provided.
|
|
Brightness Adjustment
|
Manual: Adjustable to one of seven levels Colour Tone Adjustment: 4 settings
|
|
|
Capacitive method with menu functions, Quick Control settings, playback operations, and magnified display. AF point selection in still and Movies, touch shutter is possible in still photo shooting.
|
|
Display Options
|
(1) Basic Camera settings
(2) Advance Camera settings
(3) Camera settings plus histogram and dual level display
(4) No info
(5) Quick Control Screen
(6) Off
|
|
Body Materials
|
Magnesium Alloy body and Chassis with some components consisting of polycarbonate with glass fibre
|
|
Operating Environment
|
0 – 40 °C, 85% or less humidity
|
|
Dimensions (W x H x D)
|
Approx. 138.5×101.2×93.5 mm
|
|
Weight (Body Only)
|
Approx. 656 g (746 g with card and battery)
|
