Image Sensor

Type

22.3 x 14.9mm CMOS

Effective Pixels

Approx. 24.1 megapixels

Total Pixels

Approx 25.8 megapixels

Aspect Ratio

3:02

Low-Pass Filter

Built-in/Fixed

Sensor Cleaning

EOS integrated cleaning system

Colour Filter Type

Primary Colour

Image Processor

Type

DIGIC 8

Lens

Lens Mount

EF-M (EF and EF-S lenses compatible via Mount adapter EF-EOS M)

Focal Length

Equivalent to 1.6x the focal length of the lens

Image Stabilisation

Optical Image Stabilizer on compatible lens

Movie: In-camera Digital IS available. Further stabilisation enhancements from lenses compatible with Dynamic IS

Focusing

Type

Dual Pixel CMOS AF System.  Phase detection pixels built onto imaging sensor

Contrast detection method is used during 4K Movie Servo AF

AF System / Points

Maximum 3975 positions

Maximum 143/99 points available for automatic selection in Face+Tracking mode. May vary depending on settings.

Max 25 frames in Zone AF1

Freely position 1 AF point/ 1 AF Zone via manual selection (area available lens dependent)

AF Working Range

EV -4 - 18 (at 23 °C, ISO 100, with EF-M 32mm f/1.4 STM)

AF Modes

One-Shot AF and Servo AF

AF Point Selection

Face + Tracking: Face and subject tracking via automatic recognition/ manual selection via touchscreen. Automatic selection over AF points when no face recognised within frame.

Eye AF available2
Zone AF: Manual zone selection, plus automatic selection over AF points within selected zone

1-point AF / Spot AF: Manual selection via touchscreen/ buttons

Selected AF Point Display

Indicated on LCD monitor/ EVF

AF Lock

Locked when shutter button is pressed half way or customisable AE Lock Button

AF Assist Beam

via LED assist beam

Manual Focus

With EF & EF-S lenses - Select via AF/MF switch on lens

With EF-M lenses - Select via dedicated MF Button/ other customisable buttons (toggle AF/MF).

MF Peaking available
AF+MF available (Manual focus adjustment after One-Shot AF)
Magnify image available during MF (5x or 10x)

Exposure Control

Metering Modes

Real-time metering from the image sensor
(1) Evaluative metering (384 zones)
(2) Partial metering at center (approx. 5.8% of Live View Screen)
(3) Center weighted average metering
(4) Spot metering (approx. 2.9% of Live View Screen)

Partial and spot metering not available in movie

Metering Brightness Range

Still image: EV -2 - 20 (at 23 °C, ISO 100)
Movie: EV 0 - 20 (at 23 °C, ISO 100)

AE Lock

Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock Button in creative zone modes.

Exposure Compensation

+/-3 EV in 1/3 stop increments

AEB

3 shots, +/- 2 EV, 1/3-stop increments (can be used together with Exposure Compensation)

ISO Sensitivity

ISO AUTO (minimum 100, maximum can be set between 400 - 25600 except in Scene Intelligent Auto and Creative Filter mode max 6400, and Flash On 1600), 100 - 25600 in 1/3 stop increments. ISO can be expanded to 51200

4K Movie: ISO AUTO (100 - 6400), 100 - 6400 in 1/3-stop increments. Full HD and HD Movie: ISO AUTO (100 - 12800), ISO 100 - 12800 in 1/3-stop increments. ISO can be expanded to 25600

Shutter

Type

Electronically controlled focal-place shutter 3

Speed

30 - 1/4000 sec (1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)

White Balance

Type

Auto white balance with the imaging sensor

Settings

Auto (Ambience Priority), Auto (White Priority), Daylight, Shade, Cloudy, Tungsten light, White
Fluorescent light, Flash, Custom, Colour Temperature (100 Kelvin increments)

White balance compensation:
1. Blue/Amber +/-9 levels
2. Magenta/ Green +/-9 levels

Custom White Balance

Yes, 1 setting can be registered

Viewfinder

Type

0.39-type OLED Electronic Viewfinder
Approx. 2,360,000 dots

Coverage (Vertical/Horizontal)

Approx 100%

Eyepoint

Approx 22mm

Dioptre Correction

Yes

Viewfinder Information

Customisable and toggle via INFO. Button
(1) Liveview image with exposure info
(2) Liveview image with basic info
(3) Liveview image with full info

Customisable settings:
Grid overlay (x3 formats), Histogram (Brightness/ RGB), Electronic Level, Multi aspect ratios

Depth of Field Preview

Yes

LCD Monitor

Type

7.5 cm (3.0”) Touchscreen LCD (TFT). 3:2 aspect ratio. Approx. 1,040,000 dots. Electrostatic capacitive type. Vari-Angle

Coverage

Approx 100%

Brightness Adjustment

Adjustable to one of seven levels

Display Options

Customisable and toggle via INFO. Button
(1) Liveview image with exposure info
(2) Liveview image with basic info
(3) Liveview image with full info

Customisable settings:
Grid overlay (x3 formats), Histogram (Brightness/ RGB), Electronic Level, Multi aspect ratios, Hints and Tips

Flash

Built-in Flash GN (ISO 100, meters)

5

Built-in Flash Coverage

Maximum coverage at approx. 15mm (35mm equivalent: approx. 24mm)

Built-in Flash Recycle Time

Approx. 3 seconds 4

Modes

Auto (E-TTL II), Manual (minimum/medium/maximum)

Red-Eye Reduction

Yes

X-Sync

1/200 sec

Flash Exposure Compensation

+/- 2 EV in 1/3 increments

Flash Exposure Lock

Yes

Second Curtain Synchronisation

Yes

Multi-Function Shoe / HotShoe / PC Terminal

Yes/No

External Flash Compatibility

E-TTL II with EX and EL series Speedlites, wireless multi-flash support

External Flash Control

Via camera setting/ flash setting menu

Shooting

Modes

Scene Intelligent Auto, Hybrid Auto, Creative Assist, SCN(Self-Portrait, Portrait, Night Portrait, Smooth Skin, Landscape, Sports, Close-up, Food, Panning, Handheld Night Scene, HDR Backlight Control, Silent Mode), Creative Filters (Grainy B/W, Soft Focus, Fish-eye Effect, Water painting effect, Toy camera effect, Miniature effect , HDR Art standard, vivid, bold, embossed), Program AE , Shutter priority AE, Aperture priority AE, Manual exposure, Movie (Movie auto exposure, Movie manual exposure, Time-lapse movie)

Picture Styles

Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)

Colour Space

sRGB and Adobe RGB

Image Processing

Highlight Tone Priority (standard and enhanced)

Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings + Multi Shot NR)
Lens peripheral illumination correction
Chromatic aberration correction
Diffraction correction
Digital Lens Optimizer (DLO)

Creative Assist:
Presets
Background Blur (5 settings)
Brightness (19 levels)
Contrast (9 levels)
Saturation (9 levels)
Color Tone 1 & 2 (19 levels)
Monochrome (Off/Black and white/Sepia/Blue/Purple/Green)

Drive Modes

Single, High-Speed Continuous, Low-Speed Continuous, Self timer (2s, 10s, Remote)

Continuous Shooting

One shot AF: Approx. 10 shots/sec for up to 36 frames in JPEG and 10 frames in RAW5

Live View Mode

Coverage

Approx. 100% (horizontally and vertically)

File Type

Still Image Type

JPEG: Fine, Normal (Exif 2.31 compliant) / Design rule for Camera File system (2.0)
RAW: RAW, C-CRAW (CR3 14-bit) [6],Digital Print Order Format [DPOF] Version 1.1 compliant

RAW+JPEG Simultaneous Recording

Yes, RAW + various JPEG compression possible

Image Size

RAW: 6000 x 4000

JPEG 3:2: (L) 6000 x 4000, (M) 3984 x 2656, (S1) 2976 x 1984, (S2) 2400 x 1600
JPEG 4:3: (L) 5328 x 4000, (M) 3552 x 2664, (S1) 2656 x 1992, (S2) 2112 x 1600
JPEG 16:9: (L) 6000 x 3368, (M) 3984 x 2240, (S1) 2976 x 1680 (S2) 2400 x 1344
JPEG 1:1: (L) 4000 x 4000, (M) 2656 x 2656, (S1) 1984 x 1984, (S2) 1600 x 1600"

Folders

New folders can be created and selected

File Numbering

(1) Continuous, Auto Reset
(2) Manual Reset

EOS Movie

Movie Type

MP4 [Video: MPEG-4 AVC/H.264, Audio: MPEG-4 AAC-LC (stereo)]

Movie Size

4K - 3840 x 2160 (23.98, 25 fps)
Full HD - 1920 x 1080 (59.94, 50, 29.97, 25, 23.976 fps)
HD - 1280 x 720 (119.9, 100, 59.94, 50 fps)

Movie Length

Max duration 29min 59sec, Max file size 4GB7

Interface

Computer

Hi-Speed USB (Micro USB)

Other

Wireless LAN (IEEE802.11b/g/n), (2.4 GHz only, 1-11 ch)8
Bluetooth® (Specification version 4.2, Bluetooth low energy technology)
HDMI (Micro - Type-D connector), HDR output to compatible TV supported

Storage

Type

SD, SDHC, SDXC (UHS-I compatible)

Supported Operating System

PC

See support pages for up-to-date information

Macintosh

See support pages for up-to-date information

Software

Image Processing

Digital Photo Professional

Other

Picture Style Editor, EOS Utility, Image Transfer Utility
Camera Connect app available on iOS and Android devices

Power Source

Batteries

1 x Rechargeable Li-ion Battery LP-E12

Battery Life

Viewfinder: Approx. 250 shots (at 23°C, AE 50%, FE 50%)12Live view: Approx 305 shots (at 23°C, AE 50%, FE 50%)134K Movie Recording: Approx. 95 mins
Full HD Movie Recording: Approx 130 mins
Playback time when playing back a slideshow of still images: Approx. 3 hrs 45 mins

Battery Indicator

4 levels

Power Saving

Display off (15, 30 sec or 1, 3, 5, 10, 30 mins)
Auto Power Down (30 sec or 1, 3, 5, 10 mins, Disable)
Viewfinder off (1, 3 min, disable)

ECO mode

Power Supply & Battery Chargers

Battery charger LC-E12
Compact Power Adapter CA-PS700
DC Coupler DR-E12

Battery charger LC-E12

Physical Specifications

Body Materials

Polycarbonate

Operating Environment

0 – 40 °C, 85% or less humidity

Dimensions (W x H x D)

116.3 x 88.1 x 58.7mm

Weight (Body Only)

Approx 387g (black), 388g (white), CIPA testing standard including battery and memory card
